Switch: vandal resistant; Pos: 2; SPST; 2A/36VDC; OFF-(ON); white

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: 2213775-1
    Manufacturer: TE Connectivity
    Manufacturer code: 2213775-1
    • Mounting
    • Operating temperature
    • IP rating
    • Type of switch
    • Contact plating
    • Number of positions
    • Leads
    • Contact material
    • Max. contact resistance:
    • Flammability rating
    • Mounting hole diameter
    • Body colour
    • Mechanical durability
    • Backlight colour
    • Illumination
    • Illumination
    • Min. insulation resistance
    • Electrical life
    • Key stroke
    • Contacts configuration
    • DC contacts rating @R
    • Switching method
    • Stable positions number
    • Operating Force
    • Actuator colour
    • Button shape

    19.46 € 19.46 € (wo VAT) 19.46 EUR

    19.46 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Switch: vandal resistant; Pos: 2; SPST; 2A/36VDC; OFF-(ON); white

    Mounting on panel
    Operating temperature -20...70°C
    IP rating IP67
    Type of switch vandal resistant
    Contact plating silver plated
    Number of positions 2
    Leads connectors
    Contact material copper
    Max. contact resistance: 50mΩ
    Flammability rating UL94V-0
    Mounting hole diameter Ø16mm
    Body colour silver
    Mechanical durability 1000000cycles
    Backlight colour white
    Illumination ring, LED
    Min. insulation resistance 1GΩ
    Electrical life 200000cycles
    Key stroke 2mm
    Contacts configuration SPST
    DC contacts rating @R 2A / 36V DC
    Switching method OFF-(ON)
    Stable positions number 1
    Operating Force 4.5N
    Actuator colour silver
    Button shape round
