PLUG, 2P LATCHED POKE-IN WTW CONN.NL

    Multiples: 1.0
    Minimum quantity: 5.0
    Product code: 2834048-1
    Manufacturer: TE Connectivity
    Manufacturer code: 2834048-1
    • Operating temperature
    • IP rating
    • Contacts pitch
    • Electrical mounting
    • Connector
    • Kind of connector
    • Mechanical mounting
    • Colour
    • Contact plating
    • Enclosure material
    • Type of connector
    • Number of pins
    • Contact material
    • Body material
    • Flammability rating
    • Maximum current
    • Current rating
    • Rated voltage
    • Locking system
    • Spatial orientation

    0.63 € 0.63 € (wo VAT) 0.63 EUR

    0.63 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for PLUG, 2P LATCHED POKE-IN WTW CONN.NL

    Operating temperature -40...125°C
    IP rating IP66
    Contacts pitch 4.5mm
    Electrical mounting crimped
    Connector plug
    Kind of connector male
    Mechanical mounting for cable
    Colour natural
    Contact plating tinned
    Enclosure material polyamide
    Type of connector wire-wire
    Number of pins 2
    Contact material copper alloy
    Body material polyamide
    Flammability rating UL94V-0
    Maximum current 9A
    Current rating 9A
    Rated voltage 600V DC
    Locking system for latch
    Spatial orientation straight
