Relay: reed; SPST-NO; Ucoil: 24VDC; 1A; max.200VDC; max.200VAC; 10W

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: 1-1393763-4
    Manufacturer: TE Connectivity
    Manufacturer code: 1-1393763-4
    • Mounting
    • Operating temperature
    • Body dimensions
    • Switched voltage
    • Switched voltage
    • Min. insulation resistance
    • Switching capacity
    • Coil resistance
    • Rated coil voltage
    • Contacts configuration
    • Contact resistance
    • Contact current max.
    • Type of relay
    • Coil power consumption
    • Operate time
    • Release time

    0.00 € 0.00 € (wo VAT) 0.0 EUR

    0.00 €

    This combination does not exist.

    Add to Cart

    Specification for Relay: reed; SPST-NO; Ucoil: 24VDC; 1A; max.200VDC; max.200VAC; 10W

    Mounting PCB
    Operating temperature -40...85°C
    Body dimensions 19.3x6.4x5.1mm
    Switched voltage max. 200V AC, max. 200V DC
    Min. insulation resistance 1GΩ
    Switching capacity 10W
    Coil resistance 2kΩ
    Rated coil voltage 24V DC
    Contacts configuration SPST-NO
    Contact resistance 150mΩ
    Contact current max. 1A
    Type of relay reed
    Coil power consumption 288mW
    Operate time 0.75ms
    Release time 0.15ms
