Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 10A/250VAC; 10A

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: 1440007-2
    Manufacturer: TE Connectivity
    Manufacturer code: 1440007-2
    • Mounting
    • Operating temperature
    • Contact material
    • Terminal pitch
    • Height
    • Body dimensions
    • Switched voltage
    • Switched voltage
    • Coil resistance
    • Rated coil voltage
    • Contacts configuration
    • DC contacts rating @R
    • AC contacts rating @R
    • Contact current max.
    • Relay variant
    • Type of relay
    • Coil voltage min.
    • Operate time
    • Release time

    2.99 € 2.99 € (wo VAT) 2.99 EUR

    2.99 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 10A/250VAC; 10A

    Mounting PCB
    Operating temperature -30...70°C
    Contact material AgCdO
    Terminal pitch 2.54mm
    Height 14.7mm
    Body dimensions 18.2x14.7x10.2mm
    Switched voltage max. 30V DC, max. 277V AC
    Coil resistance 1.28kΩ
    Rated coil voltage 24V DC
    Contacts configuration SPST-NO
    DC contacts rating @R 10A / 30V DC
    AC contacts rating @R 10A / 250V AC
    Contact current max. 10A
    Relay variant miniature
    Type of relay electromagnetic
    Coil voltage min. 16.8V DC
    Operate time 10ms
    Release time 4ms
