Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 10A/250VAC; 10A

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: 2-1393194-1
    Manufacturer: TE Connectivity
    Manufacturer code: 2-1393194-1
    • Mounting
    • Operating temperature
    • Contact material
    • Height
    • Body dimensions
    • Mechanical durability
    • Switched voltage
    • Switched voltage
    • Coil resistance
    • Rated coil voltage
    • Contacts configuration
    • AC contacts rating @R
    • Contact current max.
    • Relay variant
    • Type of relay
    • Coil voltage min.
    • Coil power consumption
    • Operate time
    • Release time

    2.97 € 2.97 € (wo VAT) 2.97 EUR

    2.97 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 10A/250VAC; 10A

    Mounting THT
    Operating temperature -30...85°C
    Contact material AgCdO
    Height 14.7mm
    Body dimensions 18.2x14.7x10.2mm
    Mechanical durability 10000000cycles
    Switched voltage max. 30V DC, max. 277V AC
    Coil resistance 1.28kΩ
    Rated coil voltage 24V DC
    Contacts configuration SPST-NO
    AC contacts rating @R 10A / 250V AC
    Contact current max. 10A
    Relay variant miniature
    Type of relay electromagnetic
    Coil voltage min. 16.8V DC
    Coil power consumption 450mW
    Operate time 10ms
    Release time 4ms
