Relay: electromagnetic; SPST-NO; Ucoil:24VDC; 40A; Mounting: PCB

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: HF105F-1/024D-1HS
    Manufacturer:
    Manufacturer code:
    • Mounting
    • Operating temperature
    • Contact material
    • Body dimensions
    • Weight
    • Mechanical durability
    • Switched voltage
    • Switched voltage
    • Switching capacity
    • Switching capacity
    • Coil resistance
    • Rated coil voltage
    • Contacts configuration
    • DC contacts rating @R
    • Contact resistance
    • AC contacts rating @R
    • Contact current max.
    • Relay variant
    • Type of relay
    • Coil voltage min.
    • Coil power consumption

    2.97 € 2.97 € (wo VAT) 2.97 EUR

    2.97 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Relay: electromagnetic; SPST-NO; Ucoil:24VDC; 40A; Mounting: PCB

    Mounting PCB
    Operating temperature -55...85°C
    Contact material AgCdO
    Body dimensions 32.3x27.1x20mm
    Weight 36g
    Mechanical durability 10000000cycles
    Switched voltage max. 28V DC, max. 277V AC
    Switching capacity 560W, 7.2kVA
    Coil resistance 660Ω
    Rated coil voltage 24V DC
    Contacts configuration SPST-NO
    DC contacts rating @R 20A / 28V DC
    Contact resistance 50mΩ
    AC contacts rating @R 30A / 240V AC
    Contact current max. 40A
    Relay variant power
    Type of relay electromagnetic
    Coil voltage min. 18V DC
    Coil power consumption 900mW
