Test needle; Operational spring compression: 2mm; 3A; Ø: 1.5mm

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: HFS-810 303 150 A 5302 D
    Manufacturer: INGUN
    Manufacturer code: HFS-810 303 150 A 5302 D
    • Mounting
    • Operating temperature
    • Contact plating
    • Contact material
    • Length
    • Impedance
    • Current rating
    • Max. frequency
    • Flange diameter
    • Tip diameter
    • Type of test accessories
    • Operational spring compression
    • Blade tip shape

    275.21 € 275.21 € (wo VAT) 275.21 EUR

    275.21 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Test needle; Operational spring compression: 2mm; 3A; Ø: 1.5mm

    Mounting push-in
    Operating temperature -40...80°C
    Contact plating gold-plated
    Contact material CuBe
    Length 43mm
    Impedance 50Ω
    Current rating 3A
    Max. frequency 2GHz
    Flange diameter 6mm
    Tip diameter 1.5mm
    Type of test accessories test probe
    Operational spring compression 2mm
    Blade tip shape flat
