Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 50mA

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: RM699BV-3211-85-1024
    Manufacturer: RELPOL
    Manufacturer code: RM699BV-3211-85-1024
    • Mounting
    • Operating temperature
    • IP rating
    • Contact material
    • Body dimensions
    • Current rating
    • Switched voltage
    • Switched voltage
    • Coil resistance
    • Rated coil voltage
    • Contacts configuration
    • DC contacts rating @R
    • Contact resistance
    • AC contacts rating @R
    • Relay variant
    • Coil voltage max.
    • Type of relay
    • Coil voltage min.
    • Coil power consumption
    • Operate time
    • Release time

    0.00 € 0.00 € (wo VAT) 0.0 EUR

    0.00 €

    This combination does not exist.

    Add to Cart

    Specification for Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 50mA

    Mounting PCB
    Operating temperature -40...85°C
    IP rating IP67
    Contact material AgSnO<sub>2</sub>
    Body dimensions 28x5x15mm
    Current rating 50mA
    Switched voltage max. 30V AC, max. 36V DC
    Coil resistance 3.39kΩ
    Rated coil voltage 24V DC
    Contacts configuration SPDT
    DC contacts rating @R 0.05A / 36V DC
    Contact resistance 30mΩ
    AC contacts rating @R 0.05A / 30V AC
    Relay variant miniature
    Coil voltage max. 36V DC
    Type of relay electromagnetic
    Coil voltage min. 18V DC
    Coil power consumption 170mW
    Operate time 8ms
    Release time 4ms
