Sensor: laser; Range: 0÷15m; PNP/NPN; DARK-ON,LIGHT-ON; 100mA

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: WL12L-2B520
    Manufacturer: SICK
    Manufacturer code: WL12L-2B520
    • Supply voltage
    • Max. operating current
    • Operating temperature
    • IP rating
    • Number of pins
    • Body material
    • Body dimensions
    • Range
    • Output configuration
    • Type of sensor
    • Sensors features
    • Sensors features
    • Sensors features
    • Connection
    • Operation mode
    • Switching frequency max
    • Operation modes
    • Operation modes

    747.01 € 747.01 € (wo VAT) 747.01 EUR

    747.01 €

    This combination does not exist.

    Add to Cart

    Specification for Sensor: laser; Range: 0÷15m; PNP/NPN; DARK-ON,LIGHT-ON; 100mA

    Supply voltage 10...30V DC
    Max. operating current 100mA
    Operating temperature -10...50°C
    IP rating IP67
    Number of pins 5
    Body material zinc die-cast
    Body dimensions 15x49x41.5mm
    Range 0...15m
    Output configuration PNP/NPN
    Type of sensor laser
    Sensors features laser red 650nm, Reflector must be ordered separately., sensitivity adjustable
    Connection connector M12
    Operation mode retro-reflective
    Switching frequency max 2.5kHz
    Operation modes DARK-ON, LIGHT-ON
