Relay: reed; SPDT; Ucoil: 5VDC; 1.2A; max.175VDC; 3W; Rcoil: 200Ω

    Kordarv: 1.0
    Minimum quantity: 1.0
    Tootekood: 2-1393763-2
    Tootja: TE Connectivity
    Tootja tootekood: 2-1393763-2
    • Mounting
    • Operating temperature
    • Body dimensions
    • Switched voltage
    • Min. insulation resistance
    • Switching capacity
    • Coil resistance
    • Rated coil voltage
    • Contacts configuration
    • Contact resistance
    • Contact current max.
    • Type of relay
    • Coil power consumption
    • Operate time
    • Release time

    0,00 € 0,00 € (KM-TA) 0.0 EUR

    0,00 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Product downloads

    Spetsifikatsioon tootele Relay: reed; SPDT; Ucoil: 5VDC; 1.2A; max.175VDC; 3W; Rcoil: 200Ω

    Mounting PCB
    Operating temperature -40...85°C
    Body dimensions 19.3x7x7.5mm
    Switched voltage ≤ 175V DC
    Min. insulation resistance 1GΩ
    Switching capacity 3W
    Coil resistance 200Ω
    Rated coil voltage 5V DC
    Contacts configuration SPDT
    Contact resistance 150mΩ
    Contact current max. 1.2A
    Type of relay reed
    Coil power consumption 125mW
    Operate time 1.1ms
    Release time 1.6ms
