Mounting
on panel
Supply voltage
20...350V DC
Operating temperature
0...50°C
IP rating
IP65 (from the front)
IP rating
IP20 at terminal side
Mounting hole diameter
92x46mm
Body dimensions
96x48x79mm
Kind of display used
LED
Additional functions
signalling of detected errors with a messages on the display, signal digital filtering, sensors supply voltage 24V DC / 30mA
Additional functions
temperature compensation of thermocouple cold ends
Additional functions
universal input (selected from keypad)
Kind of input 1
0...10V DC
Kind of input 1
0...20mA
Kind of input 1
0...60mV
Kind of input 1
4...20mA
Kind of input 1
universal
Kind of temperature sensor
Ni100
Kind of temperature sensor
Pt100
Kind of temperature sensor
Pt500
Kind of temperature sensor
Pt1000
Kind of temperature sensor
thermocouple B
Kind of temperature sensor
thermocouple J
Kind of temperature sensor
thermocouple K
Kind of temperature sensor
thermocouple R
Kind of temperature sensor
thermocouple S
Kind of temperature sensor
thermocouple T
Controlled parameter
humidity
Controlled parameter
pressure
Controlled parameter
speed
Controlled parameter
temperature
Kind of output 1
0...10V
Kind of output 1
2...10V
The programming method
keypad
Input 1 properties
analogue voltage
Input 1 properties
current analog
Input 1 properties
RTD
Input 1 properties
thermocouple
Display height 1
20mm
168,86 €168,86 €(KM-TA)
168.86
EUR
168,86 €
