Relay: electromagnetic power; DPST-NO + SPST-NC; Ucoil: 12VDC

    Kordarv: 1.0
    Minimum quantity: 1.0
    Tootekood: AZEV200-2AE1B-12D
    Tootja: ZETTLER
    Tootja tootekood: AZEV200-2AE1B-12D
    • Mounting
    • Operating temperature
    • Contact material
    • Switched voltage
    • Rated coil voltage
    • Contacts configuration
    • Contact resistance
    • Contact current max.

    25,07 € 25,07 € (KM-TA) 25.07 EUR

    25,07 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Product downloads

    Spetsifikatsioon tootele Relay: electromagnetic power; DPST-NO + SPST-NC; Ucoil: 12VDC

    Mounting PCB
    Operating temperature -40...95°C
    Contact material AgSnO<sub>2</sub>
    Switched voltage ≤ 480V AC
    Rated coil voltage 12V DC
    Contacts configuration DPST-NO + SPST-NC
    Contact resistance 2mΩ
    Contact current max. 40A
