Relay: electromagnetic; DPST-NO; Ucoil: 5VDC; 8A/250VAC; 8A/30VDC

    Kordarv: 50.0
    Minimum quantity: 50.0
    Tootekood: DK2A-L2-5V
    Tootja: PANASONIC
    Tootja tootekood: DK2A-L2-5V
    • Mounting
    • Operating temperature
    • Contact plating
    • Contact material
    • Body dimensions
    • Mechanical durability
    • Switched voltage
    • Switched voltage
    • Coil resistance
    • Rated coil voltage
    • Contacts configuration
    • DC contacts rating @R
    • AC contacts rating @R
    • Contact current max.
    • Relay variant
    • Relay variant
    • Type of relay
    • Coil voltage min.
    • Coil power consumption
    • Coil current

    11,75 € 11,75 € (KM-TA) 11.75 EUR

    11,75 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Product downloads

    Spetsifikatsioon tootele Relay: electromagnetic; DPST-NO; Ucoil: 5VDC; 8A/250VAC; 8A/30VDC

    Mounting PCB
    Operating temperature -40...65°C
    Contact plating gold-plated
    Contact material AgNi + Au
    Body dimensions 20x15x9.7mm
    Mechanical durability 50000000cycles
    Switched voltage ≤ 125V DC, ≤ 250V AC
    Coil resistance 125Ω
    Rated coil voltage 5V DC
    Contacts configuration DPST-NO
    DC contacts rating @R 8A / 30V DC
    AC contacts rating @R 8A / 250V AC
    Contact current max. 8A
    Relay variant bistable, miniature
    Type of relay electromagnetic
    Coil voltage min. 3.5V DC
    Coil power consumption 200mW
    Coil current 40mA
