Test needle; Operational spring compression: 4mm; 5A; Ø: 1mm; 0.8N

    Kordarv: 1.0
    Minimum quantity: 1.0
    Tootekood: GKS-112 302 100 A 0805 M
    Tootja: INGUN
    Tootja tootekood: GKS-112 302 100 A 0805 M
    • Mounting
    • Operating temperature
    • Contact plating
    • Contact material
    • Max. contact resistance
    • Current rating
    • Tip diameter
    • Type of test accessories
    • Operational spring compression
    • Maksimum spring compression
    • Blade tip shape

    0,00 € 0,00 € (KM-TA) 0.0 EUR

    0,00 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Product downloads

    Spetsifikatsioon tootele Test needle; Operational spring compression: 4mm; 5A; Ø: 1mm; 0.8N

    Mounting screw-in
    Operating temperature -40...80°C
    Contact plating gold-plated
    Contact material CuBe
    Max. contact resistance 20mΩ
    Current rating 5A
    Tip diameter 1mm
    Type of test accessories test probe
    Operational spring compression 4mm
    Maksimum spring compression 8mm
    Blade tip shape flat
