Test needle; Operational spring compression: 3.5mm; 8A; Ø: 1mm

    Kordarv: 1.0
    Minimum quantity: 1.0
    Tootekood: GKS-427 313 100 A 2502 M
    Tootja: INGUN
    Tootja tootekood: GKS-427 313 100 A 2502 M
    • Mounting
    • Operating temperature
    • Contact plating
    • Contact material
    • Max. contact resistance
    • Length
    • Current rating
    • Tip diameter
    • Type of test accessories
    • Maksimum spring compression
    • Blade tip shape

    0,00 € 0,00 € (KM-TA) 0.0 EUR

    0,00 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Product downloads

    Spetsifikatsioon tootele Test needle; Operational spring compression: 3.5mm; 8A; Ø: 1mm

    Mounting screw-in
    Operating temperature -40...80°C
    Contact plating gold-plated
    Contact material CuBe
    Max. contact resistance 20mΩ
    Length 19.5mm
    Current rating 8A
    Tip diameter 1mm
    Type of test accessories test probe
    Maksimum spring compression 4.5mm
    Blade tip shape rounded
