Sensor: ultrasonic; straight; Range: 50÷800mm; 0-10V analogue

    Kordarv: 1.0
    Minimum quantity: 1.0
    Tootekood: UB800-18GM40-U-V1
    Tootja: PEPPERL+FUCHS
    Tootja tootekood: UB800-18GM40-U-V1
    • Supply voltage
    • Max. operating current
    • Operating temperature
    • IP rating
    • Number of pins
    • Body material
    • Range
    • Output configuration
    • Kind of sensor
    • Plating material
    • Type of sensor
    • Connection
    • Switch housing

    348,56 € 348,56 € (KM-TA) 348.56 EUR

    348,56 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Product downloads

    Spetsifikatsioon tootele Sensor: ultrasonic; straight; Range: 50÷800mm; 0-10V analogue

    Supply voltage 15...30V DC
    Max. operating current 200mA
    Operating temperature -25...70°C
    IP rating IP67
    Number of pins 4
    Body material brass
    Range 50...800mm
    Output configuration 0-10V analogue
    Kind of sensor straight
    Plating material nickel
    Type of sensor ultrasonic
    Connection connector M12
    Switch housing M18
