    2. Display: TFT; 7"; 800x480; Window dimensions: 153.84x85.63mm; 5VDC
    Public Pricelist

    Display: TFT; 7"; 800x480; Window dimensions: 153.84x85.63mm; 5VDC

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: GEN4-ULCD-70P4
    Manufacturer: 4D Systems
    Manufacturer code: GEN4-ULCD-70P4
    Certificates:
    • Supply voltage
    • Operating temperature
    • Interface
    • Interface
    • Interface
    • Interface
    • Interface
    • Operating current
    • Type of pin configuration
    • Microcontroller
    • Display resolution
    • Display features
    • Display features
    • Display features
    • Screen size
    • Kind of display
    • Contrast
    • Window dimensions (H x W)
    • Type of display

    196.68 € 196.68 € (wo VAT) 196.68 EUR

    196.68 €

    This combination does not exist.

    Add to Cart

    Product downloads

    Specification for Display: TFT; 7"; 800x480; Window dimensions: 153.84x85.63mm; 5VDC

    Supply voltage 5V DC
    Operating temperature -15...65°C
    Interface analog, GPIO, I2C, PWM, UART
    Operating current 760mA
    Type of pin configuration 1x30
    Microcontroller PIXXI-44
    Display resolution 800x480
    Display features mounting frame, smart, microSD card reader
    Screen size 7"
    Kind of display graphical
    Contrast 500:1
    Window dimensions (H x W) 153.84x85.63mm
    Type of display TFT
